Water pump production line

Main classifications and application scenarios of water pumps

Centrifugal pump: agricultural water conservancy    Advantages: Large flow and low lift, suitable for drip irrigation/sprinkler irrigation systems

Pipeline pump: Advantages of industrial cycle: Temperature resistance of 120 ° C, suitable for factory cooling/heating medium transportation

Multi-stage centrifugal pump: municipal water supply     Advantages: Multi-level pressurization ensures stable water pressure in high-rise buildings

Diesel engine-driven centrifugal pump: Emergency fire protection advantages: It can be started when power is cut off, meeting emergency high-lift needs

Core advantages of water pump production line:

Standardization process of water pump production line:

Adopt a "linear + U-shaped" mixed layout, and set up six fixed stations of "parts sorting → motor/pump body pre-assembly → impeller/sleeve assembly → seal debugging → whole machine testing → packaging", which makes the process connection compact and reduces material handling loss;

  Production line automation assistance: key processes are equipped with pneumatic torque wrenches (bolt tightening accuracy ±2N·m), electric tightening machines (torque consistency ±3%), and automatic glue coating machines (uniform and controllable sealant thickness) to reduce manual errors, reduce single pump assembly time to 8-15 minutes;

  Flexible production: Support "quick switching of multiple models"-by replacing tooling fixtures (adapting to the positioning of pump bodies with different diameters) and adjusting the process rhythm (the beat of a single pump can be fast or slow),"small batches of multiple models"(200 units per day, replacement time ≤30 minutes) and "large batches of single model"(500 units per day) are flexibly switched;

The water pump production line has achieved full-process quality control: a "complete machine test area" is set at the end of each water pump production line, which passes pressure test (simulating the actual working condition head error of ±2%), leak detection (electronic leak detector accuracy of 0.01mL/min), and no-load test run (no abnormalities in 30 minutes) to ensure that each pump meets the standards when leaving the factory.

Our water pump production line adopts advanced production processes and equipment, and has standardized operating procedures to ensure operating specifications and improve the efficiency, stability and reliability of water pump products. The water pump production line uses automated equipment instead of manual handling and repeated operations. Automation of key processes (tightening, press-fitting, gluing) reduces human error, and each process is carefully controlled. At the same time, we provide customized water pump production line solutions to tailor the most suitable water pump production line according to the production scale and needs of different customers, helping companies improve production efficiency and product quality.
